Three system Computerized Flat Knitting Machine Series

Three system Computerized Flat Knitting Machine Series

QL-352M QL-366M QL-372M QL-380M

Triple system, this series have two models: with comb and without comb, with digital technology, it could implement the rib transfer, jacquard, needle narrowing and other weaving functions. also, it can knit basic knitting(full needle, single side) the weft knitted fabric like cable stitch. this applies to spun silk, synthetic filament, wool, acrylic, blending yarn and other materials, sweaters, scarfs, hats and clothing accessories.

Product Characteristics

Automatic Refueling

In order to make the machine work better, we have developed a 24-hour intelligent system for automatic refueling.

Carriage

The linear velocity of the head can reach 1.2m/s. The stroke can be adjusted according to the weaving width. Fast response and accurate location can avoid invalid movements and increase production efficiency. Each system is equipped with five functions, such as rib transfer, weaving, tuck, non-weave, and pin. In addition, it is secured by short-circuited electric magnet，motor overcurrent, Locked-Rotor, etc.

Needle Bed

Divided structure, steel sheet made from import high-quality steel precisely punched and finely polished to reduce the resistance with needles and increase the longevity.

Dynamic Stitch

The device by dynamic stitch technology, we achieve the variety of stitches and variety density in one course to improve knitting efficiency and variety.
High-speed and High-efficiency
Increase the carriage return speed and productivity as well as avoid the work of the carriage rail. In the case of 12g, the high-speed return can improve efficiency by more than 20%，compared with the old system.

Positive Yarn Provider

Positive Yarn Providing, successfully Reduce Yarn Resistance, increase Knitting Efficiency.

*roller yarn provider and yarn storage device can be selected according to the model of the machine

Touch Screen

Adopting industrial LCD, graphic interface，color display. On working conditions, ，parameters like weavingpieces， finished pieces, time, velocity，Roller，mesh number, yarn nozzle, etc. could be displayed clearly on the screen. When running，you can adjust parameters freely. This is the most convenient and time-saving device all you need to do is just focus on the fabric and input the command, and then all the parameters and pattern types could be changed.
Main Parameter

Model

QL-352M  QL-366M  QL-372M  QL-380M

Gauge

3.5G、5/7G、5G、7G、8G、9G、10G、12G、14G、16G、18G

Carriage

Single carriage with the three system

Knitting range

52"/60"/66"/80"/100"

Comb system

Zero finishing yarn comb system; regular comb system

Knitting system

Single carriage with the three systems, the adoption of digital technology to realize the horizontal machine turning needle, picking hole, lifting eye, no dotted line jacquard, four flat jacquard, Open stitch, dark stitch, and other regular pattern weaving functions.

Knitting speed

Maximum speed is 1.8 m/s without load, with 128 sections of programming speed

 Stitch density

128 sections electronic control, using subdivision technology; The stepping motor controls and adjusts the density, and the adjustable range is 0-650

Dynamic stitch

It is realized by a high-speed stepper motor, which supports the realization of multi-segment variable mesh control within a row of patterns, and the realization of a variety of fabric densities in the same line Weaving, rich weaving patterns.

Transfer

Can be turned back and back at the same time, not affected by the nose direction, minute knitting.

Racking system

Motor-driven,1/2 and 1/4 needle in any position; Maximum 2 inches on one side.

Sinker

The stepping motor can adjust the movable sinker, which can be adjusted according to different fabrics to achieve a variety of needling and needling effects.

Quickly turning

An intelligent switching braiding system improves machine weaving efficiency.

Take-down device

128 sections of automatic control, time division adjustment, can be automatically identified according to the width of the pattern automatically adjust the tension, can meet a lot of local weaving, The pulling force requirement of the pattern makes the pulling force of the fabric evenly distributed and the strength is reliable.

Trimming device

Single/ Double scissors clip (optional)

Yarn feeder device

1.5g -10G adopts a roller feeding device to accurately control the tension of the yarn and ensure the consistency of the whole woven piece quality;12G-18g adopts the yarn storage device to accurately control the tension of the yarn and ensure the consistency of the whole woven piece quality;

Safety device

The whole machine is covered to reduce noise and dust, infrared safety device, emergency stop device, cut-off power device, indicator light alarm device.

Refueling device

Automatic refueling: control the refueling time and frequency by setting the time. After the time is up, lubricate the long needle spring. The needle on the needle plate automatically reduces the wear of the machine and increases its service life.

Stop motion

Automatic stop for yarn breaking, yarn knot, fabric rewinding, firing pin, number of pieces completed, overload, program error, etc

Control system

Scree uses LCD industrial display, touch screen graphical interface. transmission mode uses USB and network, which can be med to store a large number of pattern files and can be called out and used at any time according to production needs. Monitoring screen: display all kinds of working parameters and knitted mesh value and it can be adjusted at any time when the machine is running, which is convenient for operation and time saving to the greatest extent. Plate-making system and control system (software part) SH upgrade is convenient. Support a variety of lower format CNT, HCD,000, etc. Support for multi-language operating versions (Chinese, English, Russian and other languages)

 Data input

Input data through a USB flash drive or computer connection

Blackout memory function

Advanced CMOS technology is adopted to realize blackout memory and call recovery weaving functions.

Network function

A high-speed ETHERNET network theoretically enables unlimited computer connection, data uploading and sharing, and real-time monitoring.

Power supply unit

 Voltage: AC 220V/380V; Frequency: 50HZ/60HZ; Power: 1.5KW

Size and weight of the machine

QL-3S52M ( Size: 3000*800*1700MM; Weight around：880KG)

Specifications And Configurations Should Be Subjected To The Contract.


Computerized flat knitting machine maintenance instruction
To ensure computerized flat knitting machine is in a good situation at any time, reducing wear and increase of the machine life, keep a lower operating and maintenance costs, we need to properly maintain the machine, provide a good working environment. The following points are very important and must be done:
1. Every production unit should be cleaning the needle bed with an air compressor, make sure there is no dust on the needle, yarn feeder, yarn feeder guide rail, out of the carriage, brush…cleaning the workshop regularly.
2. Add lubricant to the needle bed, needle stitch, yarn feeder guide rail, carriage guide rail, keep all the transmission parts lubricated.
3. Machine discontinued using long time or temporary, need to apply with anti-rust oil for the needle bed and other parts at first, the machine also needs to be covered.
4. Please read the instruction manual before using the machine.
